Sectional Steel Panel water Tanks
FTS Sectional Panel Water Tank are made with steel panels
and are also known as pressed steel tanks or sectional tanks and are suitable
for the storage of medium to high volumes of water and other liquids. All
Sectional Steel Panel Water Tank are hot dipped galvanized panels and can be
tailor made to serve as various industrial and residential reservoir
applications. FTS can supply and install these panel tanks in any size ranging
from 1000 to 5 Million liters. All Sectional steel Panel water Tanks
structures are signed off by a registered engineer. Panel tanks can be ground
based and serviced by a pressure vessel and pump or elevated up-to 35 meters to
create water pressure by altitude.
Sectional Steel Panel Water Tanks General Specifications
Bolt,Nuts,Washer:
External:Standard : Hot Dipped Galvanised steel
Optional: SS 304/316
Internal : Standard :
SS 304 ( IN-Contact with Water
Optional: SS316 (In - Contact with Water)
Roof : Standard : Hot Dipped Galvanised Steel
Optional : SS 304/316
Ladder:
External : Standard : Hot Dipped Galvanised steel
Internal : Standard : PVC or Aluminium
Optional :GRP Or SS 304-316
Water level indicator :
Standard : Reverse Reading Pointer Mechanical Type ( Cat
& Mouse)
Optional : Direct Reading Clear Tube Type
Nozzle Panel:
Pipe Nozzles not inclusive
Flat Panels will be provided on request
Standard:
Malaysia standard MS1390:2010. Singapore Standard SS245:
1995 British Standards BS 7491
Part3:1994 and BS EN 13280:2001
Materials:
Sheet Moulding Compound (SMC) Consist of:
Resin - Isophthalic unsaturated polyester resin conforming
to BS 3532 Specification
Fiber Glass - Low alkalli fibre glass conforming to JIS
R3411 to R3417 or BS 3396, BS 3496
and BS 3749 Specifications
Manufacturing Process:
Hot pressed SMC compression moulding
Tie -rod System : External: Hot Dipped Galvvanised Steel
Internal:SS304 Tie-rod,optional SS316
Roof Support:PVC/ABS pipes with GRP roof panel stiffener
External Braced Sysytem: External : Hot Dipped Galvanised
Steel
Internal:None (metal free insde, non Partitioned tank only)
Roof support: PVC Poles with GRP roof panel stiffener
Sealant:
Non toxic PVC foam/EPDM R
